S&S, 3-1/2" diameter piston kit 9:1CR. Standard

High 9:1 compression ratio (53cc dome). Suitable as a direct replacement for 1340 (80") Shovelhead models with 3-1/2" bore and standard 4-1/4" stroke. These S&S forged pistons are made from an advanced alloy with skirt profiles, resulting in a quiet engine and greater durability, characteristics previously only achievable with cast pistons. This is an excellent option for rebuilding your stock 1340cc Shovelhead with a higher-compression piston. Pistons include wrist pins, pin locks and piston rings.
Note: S&S piston fitting recommendations: Tight fit .0030" to .0035", loose fit .004" to .005".
Note: In all applications, the technician must be able to assess the suitability of the components in combination with the other engine components before installation. It is important that a qualified mechanic carries out the installation and any necessary adjustments. The rider must follow standard running-in and riding procedures for remanufactured engines.


Specifications


Brand
S&S


Application
79-84 1340cc/80" Shovel (NU)


Sales unit
Set


Material
Aluminium


Packaging weight
1.364 kg


HS Code
84099100


Motorcycle family
BIG TWIN, FX, FXR, SOFTAIL, TOURING


Original name
S&S, 3-1/2" bore 9:1CR piston kit. Std
